![BST106-K01B/L[GH]](/npublic/img/s.png "BST106-K01B/L[GH]")
Packing Scale Controller [four scales, four set values]
BST106-K01B/L[GH]
A weighing control instrument developed for quantitative packaging scales in industrial automation. Applicable to single/double/triple/quadruple hopper scales, with selectable packaging modes: combination scale [multi-hopper packaging]/combination scale [single-hopper packaging]/independent scale [single-hopper packaging]. Widely used in grain, feed, rubber and plastic, and chemical industries.
- 7”TFT touchscreen, aluminum alloy chassis, stainless steel back panel.
- Rich and flexible human-machine interface with multi-language switching, including Chinese and English.
- Features manual screen lock/unlock, automatic screen lock, digital setting, digital calibration, and I/O testing functions.
- Features power-on zeroing, automatic zero tracking, manual/automatic zeroing, and zero calibration functions.
- Features load calibration and tare calibration functions.
- Can store 100 sets of recipes.
- Optional "drop difference automatic correction" function.
- Optional "pause on deviation alarm" and "automatic fine feeding" functions.
- Optional "fixed batch control" function (automatic shutdown after completion of "target batch" or "target cumulative").
- Optional "flow control" function for single hopper scales.
- Can automatically print current batch records.
- Can query/print historical batch records, cumulative reports, and recipe tables.
